Welcome EIRE300 Open Frame AC-DC Power Supply
14th November 2024Share This Post
Share This Post
Relec Electronics is excited to announce the release of the EIRE300 series from Vox Power, a powerful addition to our high efficiency AC-DC power supply range designed to meet the rigorous needs of both medical and industrial applications. The EIRE300 delivers a robust 300 Watts of power in a compact 4” x 2” open-frame design, with a sleek, ultra-low 1” profile. Built to maximise both power density and efficiency, this high-performance solution is perfect for applications where space is limited, but reliability and efficiency are paramount.
The EIRE300 series is engineered to set new industry standards, boasting best-in-class power density exceeding 37.5W per cubic inch and an impressive efficiency rating of up to 95%. This level of performance minimizes energy waste, reducing operating costs and contributing to lower environmental impact. Additionally, with peak output reaching 375W for short bursts and convection-cooled ratings of 200W (at 115VAC), the EIRE300 series is designed for flexibility across a wide range of applications.
Key Features for Medical and ITE Applications
The EIRE300 series was created with the stringent needs of medical and industrial environments in mind. Designed to meet 2 x MOPP (Means of Patient Protection) standards and BF-rating for direct contact applications, it’s ideal for use in sensitive medical equipment, including surgical and critical care devices. Low leakage currents and advanced safety protections ensure that this series is suitable for environments where patient safety is paramount. Additional features include internal dual line fusing, remote sensing, and an AC_OK signal, adding another layer of versatility and ease of integration for system designers.
Wide Range of Voltage Options and Comprehensive Protections
The high efficiency AC-DC power supply, EIRE300 series, offers a wide selection of output voltages, ranging from 12V to 60V, with standard configurations at 12V, 15V, 18V, 24V, 28V, 36V, 48V, and 54V. Each output voltage is adjustable within a broad range to accommodate specific needs, making it adaptable for specialised applications with non-standard voltage requirements. To further ensure longevity and reliability, each unit includes comprehensive over-voltage, over-current, and over-temperature protections, making it resilient under challenging operational conditions.
Designed for Flexibility, Efficiency, and Long Life
The EIRE300 series is designed to excel in a variety of operating environments, compliant with the following certifications:
EMC Class B
Standards for conducted and radiated emissions
Class I and Class II
operational altitude
Up to 5000 meters
EN61558-1
For power transformer safety
EN61010-1
For measurement and laboratory equipment
EN60335-1
For household appliances
EN60601-1 & EN62368-1
For medical and ITE applications
To ensure exceptional durability and long-term performance, the EIRE300 features ultra long-life electrolytic capacitors and conformal coating as standard, offering protection against dust, moisture, and other environmental contaminants. The high-efficiency AC-DC power supply design also significantly reduces heat output, allowing for a wide operational temperature range from -40°C to +70°C. With an estimated MTBF of over 500,000 hours, the EIRE300 is built to provide dependable service for years to come.
Future-Proof Your Systems with High-Efficiency AC-DC Power
Engineered with flexibility and reliability at the forefront, the high efficiency AC-DC power supply, EIRE300 series represents Vox Power’s commitment to delivering innovative power solutions that meet the evolving demands of today’s medical and industrial sectors. Whether you are designing medical devices that require patient proximity or developing industrial equipment that needs reliable and space-efficient power, the EIRE300 is an ideal solution.
Ready to enhance your equipment designs with the EIRE300 series?
Reach out to our expert team. Let’s start a conversation today!
