APPLICATION
The Cosel PMM30 Series is a 30W medical-grade DC-DC converter designed for high-performance applications requiring compact and reliable power solutions. It features a 2” x 1” form factor, 5000VAC isolation, 2MOPP compliance, and a wide input range in both 2:1 and 4:1 configurations. With adherence to IEC/EN/ANSI/AAMI ES60601-1 standards, it provides safe and efficient power delivery for medical, industrial, and instrumentation environments, supporting operation at altitudes up to 5000m.
The converter offers single and dual output options with ±1% voltage accuracy and low ripple, ensuring precise performance. Integrated protections include overvoltage, overload, and short-circuit safeguards with automatic recovery. Operating from -40°C to +105°C, the PMM30 Series is built to endure harsh conditions, with MIL-STD-810F compliance for thermal shock and vibration. EMI/EMC performance meets Class A without external components and Class B with minimal additions, making it suitable for noise-sensitive systems.
Lightweight yet durable, the PMM30 Series is an ideal PCB-mounted solution for demanding applications requiring robust, medical-grade power conversion.
feature list
Low Power Medical Approved DC-DC Converter
2 x MOPP & 5kV Isolation
2μA patient leakage current
Single or Dual Outputs
Various Protection Features
< 1U High
IEC 60601-1 safety approved
30 watts output power
Compact 1.6”x1” mechanical package
4:1 & 2:1 input range
8mm clearance & creepage
5000VAC isolation voltage
5000m operating altitude
5 years warranty
| MODEL NUMBER | INPUT RANGE | OUTPUT | POWER |
|---|---|---|---|
| PMM30-12D | 9 - 18Vdc | 5V, 12V, 15V | 30W |
| PMM30-12S | 9 - 18Vdc | 5V, 12V, 15V, 24V | 30W |
| PMM30-24D | 18 - 36Vdc 9 - 36Vdc | 5V, 12V, 15V | 30W |
| PMM30-24DW | 9 - 36Vdc | 5V, 12V, 15V | 30W |
| PMM30-24S | 18 - 36Vdc 9 - 36Vdc | 5V, 12V, 15V, 24V | 30W |
| PMM30-24SW | 9 - 36Vdc | 5V, 12V, 15V, 24V | 30W |
| PMM30-48D | 36 - 75Vdc 18 - 75Vdc | 5V, 12V, 15V | 30W |
| PMM30-48DW | 36 - 75Vdc | 5V, 12V, 15V | 30W |
| PMM30-48S | 36 - 75Vdc 18 - 75Vdc | 5V, 12V, 15V, 24V | 30W |
| PMM30-48SW | 18 - 75Vdc | 5V, 12V, 15V, 24V | 30W |
| Please check datasheet for exact output model numbers | |||
