PMM06

The Cosel PMM06 Series is a 6W medical DC-DC converter designed for high-reliability applications requiring strict adherence to medical safety standards. It features reinforced insulation rated for 250VAC working voltage, 5000VAC input-to-output isolation, and a low patient leakage current of 2μA. With compliance to ANSI/AAMI ES60601-1, EN60601-1, and related standards, along with RoHS and REACH certifications, it is ideal for use in sensitive medical environments. Single and dual output configurations are available, with input voltage ranges of 4.5–75VDC to accommodate various applications.

This converter ensures precise performance with voltage accuracy of ±1% and low ripple and noise levels, as well as protections for overvoltage, overload, and short circuits. It operates efficiently within an ambient temperature range of -40°C to +105°C, with derating above +88°C. Built to withstand harsh conditions, the PMM06 Series meets MIL-STD-810F standards for thermal shock and vibration and integrates a built-in EMI Class A filter for superior noise immunity. Its non-conductive plastic enclosure and flame-retardant potting enhance durability and safety.

The PMM06 Series is an excellent choice for medical devices, as well as industrial and instrumentation systems requiring compact, efficient, and highly reliable power conversion with compliance to rigorous safety and environmental standards.
