X6-MTH-ORN

Processor: Nvidia ORIN NX computing power by Intel® Core™ Ultra Processor
Memory: Up to 64GB
Form Factor: Edge AI Box
Supports: Display Port, HDMI, USB, CANbus
Size: 250 x 65 x 150mm
Material: IP20
Operating Temperature -20°C to +60°C

Make an enquiry

Make an Enquiry

Product
First Name*
Last Name*
Email*
Company
Phone
City
Country*
Enquiry*
CAPTCHA
Email
This field is for validation purposes and should be left unchanged.

have a question? Contact us now

01929 555 700
sales@relec.co.uk

APPLICATION

The X6-MTH-ORN is a powerful Edge AI Box featuring Nvidia Orin NX and Intel Core Ultra processors, designed for AI inference and industrial applications. It supports remote BIOS updates, OTA management, and DFI’s OOB control engine, ensuring seamless remote operation. With multiple display options, rich I/O connectivity, and MXM expansion, it delivers flexibility for edge computing.

Equipped with Intel Core Ultra processors and up to 64GB DDR5 memory, it offers efficient AI processing. The Nvidia Orin NX AI accelerator provides up to 100 TOPS, making it ideal for machine learning and edge inference. Storage includes up to 1TB onboard SSDs, RAID-supported SATA trays, and M.2 expansion slots.

Designed for industrial environments, it features 4 USB 3.2, 4 RJ45 GbE, CAN bus, serial ports, and stacked DP/HDMI outputs. Built for reliability, it operates from -20°C to 60°C, with a rugged aluminium/SGCC build and CE, FCC, UL, and RoHS certifications. Ideal for smart surveillance, automation, and edge AI applications, it offers robust performance and remote management.

feature list

Nvidia Orin NX up to 100 TOPS
Intel Core Ultra 7 165U with 2 P-Cores, 8 E-Cores, and 12MB cache
Supports up to 64GB Dual Channel DDR5 5600MHz RAM
Intel Iris Xe Graphics with DX12, OpenGL 4.6, and Vulkan 1.2 support
Multiple expansion slots: 4 M.2 (B, E, M key) and optional MXM Type A
Rich connectivity: 4 USB 3.2, 4 RJ45 GbE, CAN bus, micro USB, serial ports
Supports multiple displays: 3 DP, 2 HDMI, VGA, and eDP options
Wide operating temperature range: -20°C to 60°C
Supports Microsoft Windows 10, 11, and Linux Ubuntu 22.04
Certified for CE, FCC Class A, RoHS, and UL 62368-1

Downloads

Click on the link below for an instant download.

X6-MTH-ORN Datasheet
